| Merk | Dell |
| Categorie | Accessoires/supplies |
| EAN Code | 5397184657614 |
| Artikelcode | DEL-338-BUIT |
| Verpakking | Stuk(s) |
| Processorfamilie | Intel Xeon E |
| Processormodel | E-2236 |
| Aantal processorkernen | 6 |
| Maximale turbofrequentie van processor | 4,8 GHz |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Processor aantal threads | 12 |
| Systeembus | 8 GT/s |
| Processor lithografie | 14 nm |
| Processor operating modes | 64-bit |
| Codenaam processor | Coffee Lake |
| Thermal Design Power (TDP) | 80 W |
| Tjunction | 100 °C |
| PCI Express slots versie | 3.0 |
| Maximaal aantal PCI Express-lijnen | 16 |
| Maximaal intern geheugen ondersteund door processor | 128 GB |
| Geheugentypen ondersteund door processor | DDR4-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor | 2666 MHz |
| Maximum intern geheugen | 128 GB |
| Aparte grafische adapter | Nee |
| Ingebouwde grafische adapter | Nee |
| Discreet grafische adapter model | Niet beschikbaar |
| On-board graphics adapter model | Niet beschikbaar |
| Producttype | Processor |
| Intel® 64 | Ja |
| Enhanced Intel SpeedStep Technology | Ja |
| Ingebouwde opties beschikbaar | Nee |
| Intel® AES New Instructions (Intel® AES-NI) | Ja |
| Execute Disable Bit | Ja |
| Ondersteunde instructie sets | SSE4.1,SSE4.2,AVX 2.0 |
| Schaalbaarheid | 1S |
| CPU configuratie (max) | 1 |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel® Virtualization Technology (VT-x) | Ja |
| ARK ID processor | 191040 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Ja |
| PCI Express configuraties | 1x16,2x8,1x8+2x4 |
| Intel® InTru™ 3D Technology | Nee |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Nee |
| Intel® Clear Video-technologie | Nee |
| Intel® VT-x with Extended Page Tables (EPT) | Ja |
| Intel® TSX-NI | Ja |
| Idle States | Ja |
| Thermal Monitoring Technologies | Ja |
| Intel® Secure Key | Ja |
| Intel® OS Guard | Ja |
| Intel® Trusted Execution Technology | Ja |
| Intel® Software Guard Extensions (Intel® SGX) | Ja |
| Verpakkingsgrootte processor | 37.5mm x 37.5mm mm |
| Intel® Quick Sync Video Technology | Nee |
| Tcase | 73 °C |
| Breedte verpakking | 70 mm |
| Diepte verpakking | 116 mm |
| Hoogte verpakking | 101 mm |
| Gewicht verpakking | 316 g |
| Type verpakking | Retaildoos |
| Ondersteunde geheugen types | DDR4-SDRAM |
| Geheugen kanaal | Dual-channel |
| Processorfabrikant | Intel |
| Component voor | Server/werkplaats |
| ECC | Ja |
| Intel® Optane™ Memory Ready | Ja |
| Box | Nee |
| Marktsegment | Server |
| Lanceringsdatum | Q2'19 |
| Status | Launched |
| Maximaal geheugen | 128 GB |
| Inclusief koeler | Nee |
| 4K-ondersteuning | Nee |
| Maximale resolutie & verversingsfrequentie (DisplayPort) | N/A |
| Grafische uitvoer | N/A |
| Intel® Memory Protection Extensions (Intel® MPX) | Ja |
| PCI Express CEM revisie | 3.0 |
| Intel® Boot Guard | Ja |
| Intel® vPro™ Platform Eligibility | Ja |
| Bus speed | 8 GT/s |
| Code geharmoniseerd systeem (HS) | 8542310001 |
| Processor-id | N/A |
| Export Control Classification Number (ECCN) | 5A992C |
| Basisfrequentie processor | 3,4 GHz |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Intel® Turbo Boost Technology 2.0 frequency | 4,8 GHz |
| Intel® Transactional Synchronization Extensions | Ja |
